Collector Chamber can Be Easily Cleaned by Opening Collector Cover. The hydro filter is required as cleaning equipment in various systems. it is added as extra protection accessory that catches large debris that can create problems. features dimensional accuracy corrosion resistant impact resistant high temperature pressure bearing capacity.
| Parameter | Specification |
|---|---|
| Product Name | PP Hydrocyclone Filter (Hydro Cyclone Filter) |
| Material | Reinforced Polypropylene (PP) / PP + Nylon / UV-protected PP |
| Connection Sizes | 2 Inch (63mm), 2.5 Inch, 3 Inch |
| Connection Type | BSP Male Threaded / Flanged / Slip-on |
| Working Pressure | Up to 6 kg/cm² (85 PSI) |
| Flow Rate | 25 m³/hr to 45 m³/hr (varies by model) |
| Dust Removal Efficiency | Up to 90% |
| Color | Black / Multicolour |
| Country of Origin | Made in India |
| Brand | POONAM |
High-Efficiency Sand Separation – Hydrodynamically designed to create maximum centrifugal action, effectively removing sand, grit, and heavy suspended particles from irrigation water.
Durable PP Construction – Manufactured from high-grade, UV-protected polypropylene (PP) and reinforced PPGF material, ensuring long-lasting durability, corrosion resistance, and reliable performance in harsh outdoor conditions.
No Corrosion or Rusting – Unlike metal filters, PP hydrocyclone filters are completely rust-proof and corrosion-resistant, making them ideal for agricultural environments.
Easy Flushing & Maintenance – Collected sand and dirt can be easily flushed out through the drain port without disassembling the unit.
Reinforced Cone Bottom – Specially designed reinforcement at the bottom of the cone prevents wear due to strong sand vortex, extending product life.
Accurate Installation – Comes with flanged PP bend or slip-on flange for precision and ease of installation.
Compact & Space-Saving Design – Horizontal and compact design suitable for well outlets and limited-space installations.
No External Power Required – Operates purely on water pressure / centrifugal force, reducing operational costs.
Drip Irrigation Systems – Pre-filtration to prevent emitter clogging from sand and silt.
Sprinkler Irrigation Systems – Protects sprinkler nozzles from abrasive particles.
Agricultural / Farm Irrigation – Ideal for pre-filtering water containing sand and dirt from borewells, canals, ponds, and rivers.
Greenhouse & Horticulture – Ensures clean water for sensitive crops.
Water Treatment Plants – Removes suspended solids in pre-treatment stages.
Aquaculture & Fisheries – Maintains water quality in fish farming.
Industrial Processes – Suitable for cooling water and process water filtration.
Well Outlet Applications – Compact horizontal design ideal for well outlets.
PP Hydrocyclone FilterA PP Hydrocyclone Filter is a specialized sand separation device engineered from high-grade polypropylene to remove heavy suspended solids from irrigation water using centrifugal force. Unlike traditional screen or disc filters, hydrocyclone filters operate without any moving parts or filter media, relying solely on water pressure to create a powerful vortex that forces sand and grit particles outward and downward into a collection chamber. The PP Hydrocyclone Filter is lightweight, corrosion-resistant, and UV-stabilized, making it ideal for long-term outdoor agricultural use. It effectively protects drip emitters, sprinkler nozzles, and pumps from abrasive wear, significantly extending the lifespan of your entire irrigation system. Poonam Industries offers premium PP Hydrocyclone Filters in 2", 2.5", and 3" sizes with various connection options. | Hydrocyclone Sand SeparatorThe Hydrocyclone Sand Separator is a highly efficient pre-filtration device designed to remove sand, grit, and other heavy particles from water before it enters the main irrigation system. Operating on the principle of centrifugal force, water enters the cylindrical chamber tangentially, creating a spinning vortex that forces heavier particles outward and downward to the collection cone, while clean water exits from the top. This sand separator is manufactured from durable, corrosion-resistant polypropylene, ensuring long service life even in abrasive water conditions. It requires no filter media, no power supply, and minimal maintenance, making it an economical and reliable solution for farmers dealing with sandy borewell water or silt-laden canal water. Ideal for drip and sprinkler irrigation systems. | 3. PP Sand FilterA PP Sand Filter (hydrocyclone type) is a robust filtration solution crafted from high-strength polypropylene to efficiently separate sand and suspended solids from agricultural water. Unlike media-based sand filters, this hydrocyclone design uses centrifugal force to spin heavy particles out of the water stream, collecting them in a lower chamber for easy flushing. The PP construction offers exceptional resistance to corrosion, UV degradation, and chemical fertilizers, ensuring reliable performance in harsh field environments. This sand filter is particularly effective as a pre-filter before disc or screen filters, reducing the load on downstream filtration components. Available in multiple sizes and connection types, our PP Sand Filters are trusted by farmers across India for borewell, canal, and pond water applications. |
Plastic Hydrocyclone FilterThe Plastic Hydrocyclone Filter is a modern, lightweight alternative to traditional metal cyclone filters, constructed entirely from high-quality engineering plastics. This filter utilizes the same centrifugal separation principle to remove sand and heavy solids from water, but offers significant advantages over metal versions including zero corrosion, rust-proof operation, and reduced weight for easier handling and installation. Manufactured from reinforced polypropylene and nylon blends, the Plastic Hydrocyclone Filter delivers exceptional durability and impact resistance. Its smooth internal surfaces minimize friction and pressure loss, maximizing filtration efficiency. Ideal for agricultural irrigation, water treatment, and aquaculture applications, this filter provides reliable, low-maintenance sand separation without the risk of rust contamination. | Polypropylene Hydrocyclone FilterThe Polypropylene Hydrocyclone Filter is engineered from premium-grade polypropylene resin, offering superior chemical resistance, UV stability, and structural integrity for demanding agricultural and industrial applications. Polypropylene's inherent corrosion resistance makes this filter ideal for use with chemically treated irrigation water, while its lightweight nature simplifies transportation and installation. The hydrocyclone design creates a powerful centrifugal action that effectively separates sand, grit, and other dense particles from the water stream. The collected solids accumulate in the conical bottom section and can be easily flushed out through the drain port. This filter requires no consumable filter media and operates solely on water pressure, making it an extremely cost-effective and sustainable filtration solution for long-term use. | Hydro Cyclone Filter for IrrigationA Hydro Cyclone Filter for Irrigation is an essential pre-filtration component for any modern agricultural irrigation system dealing with sandy or silty water sources. This filter uses centrifugal force to separate heavy particles from water without the need for screens, discs, or filter cartridges that require frequent cleaning or replacement. The water enters the cyclone chamber tangentially, creating a vortex that forces sand and grit outward and downward, while clean water spirals upward to the outlet. Designed specifically for irrigation applications, this filter protects drip emitters, sprinklers, and pumps from abrasive damage, ensuring uniform water distribution and optimal crop health. Its durable PP construction resists corrosion and UV damage, providing years of trouble-free operation in the field. |
PP Cyclone FilterThe PP Cyclone Filter is a high-performance sand separation device manufactured from UV-stabilized polypropylene, designed to remove heavy suspended solids from irrigation water through centrifugal action. This cyclone filter features a hydrodynamically optimized internal geometry that maximizes particle separation efficiency while minimizing pressure drop. The PP construction offers excellent resistance to corrosion, chemicals, and weathering, ensuring reliable performance even in the most challenging agricultural environments. The filter's compact, cylindrical design requires minimal installation space and can be mounted vertically or horizontally. Maintenance is simple and quick – just open the drain valve to flush out accumulated sand and debris. An ideal pre-filter solution for drip, sprinkler, and micro-irrigation systems. | Sand Separator FilterA Sand Separator Filter is a specialized filtration device that uses centrifugal force to efficiently remove sand, grit, and other heavy particles from water streams. Unlike conventional filters that rely on straining or trapping particles, the sand separator filter spins water at high velocity within a conical chamber, forcing dense particles outward and downward to a collection area. This process requires no filter media, no moving parts, and no external power – just water pressure. The collected sand can be periodically flushed out through a bottom drain valve. Our Sand Separator Filters are manufactured from durable, corrosion-resistant polypropylene, ensuring long service life. They are widely used as pre-filters in agricultural irrigation, groundwater pumping, and industrial water treatment applications. | Hydrocyclone Water FilterThe Hydrocyclone Water Filter is an advanced solid-liquid separation device that effectively removes sand, silt, and other suspended solids from water using centrifugal force. Water enters the hydrocyclone tangentially, creating a spiraling flow that accelerates particles outward against the filter wall. The heavier particles spiral downward to the apex (underflow) where they collect, while the cleaner water spirals upward to the overflow outlet. This hydrocyclone water filter is manufactured from high-quality polypropylene, offering excellent durability, corrosion resistance, and UV stability. It operates without any filter media, screens, or moving parts, resulting in minimal maintenance and operational costs. Ideal for agricultural irrigation, aquaculture, and industrial water pre-treatment applications. |
PP Grit SeparatorA PP Grit Separator is a specialized hydrocyclone filter designed to remove abrasive grit and sand particles from water before they can damage irrigation equipment. Constructed from rugged polypropylene, this separator offers exceptional resistance to wear and corrosion, making it ideal for handling abrasive water conditions. The centrifugal action inside the separator forces heavy grit particles outward and downward into the collection chamber, while clean water exits from the top. Regular flushing of the collection chamber removes accumulated grit, ensuring continuous efficient operation. The PP Grit Separator is an essential component for protecting drip irrigation emitters, sprinkler nozzles, pumps, and valves from premature wear and clogging, significantly reducing system maintenance costs and downtime. | Plastic Sand SeparatorThe Plastic Sand Separator offers a lightweight, corrosion-proof alternative to traditional metal sand separators, delivering the same high-efficiency sand removal capabilities with added durability benefits. Manufactured from engineering-grade polypropylene and reinforced plastics, this sand separator resists rust, chemical attack, and UV degradation, ensuring a long operational life in outdoor agricultural settings. The hydrocyclone design creates a powerful vortex that separates sand and heavy solids from water using centrifugal force, with no filter media required. The separated sand collects in the bottom cone and can be easily flushed out. This Plastic Sand Separator is ideal for borewell water with high sand content, canal water with silt, and any irrigation system requiring reliable pre-filtration. | PP DesanderA PP Desander is a highly efficient hydrocyclone filter designed specifically to remove sand and other heavy particulates from water streams. The "desander" name reflects its primary purpose – eliminating sand that can cause significant damage to irrigation systems and pumps. Manufactured from premium polypropylene, this desander offers superior corrosion resistance, UV protection, and structural strength. The hydrocyclone design generates intense centrifugal force that spins sand particles outward and downward to the collection cone, while clean water exits through the top outlet. Regular flushing of the accumulated sand ensures consistent performance. The PP Desander is an essential pre-filter for any irrigation system drawing water from sandy borewells, rivers, or canals. |
Hydrocyclone Pre-FilterThe Hydrocyclone Pre-Filter is a crucial first line of defense for irrigation systems, removing sand, grit, and heavy suspended solids before water reaches more sensitive filtration stages. As a pre-filter, it significantly reduces the sediment load on downstream disc or screen filters, extending their cleaning intervals and operational life. The hydrocyclone pre-filter operates on centrifugal force – water enters tangentially, creating a vortex that forces heavy particles outward and downward, while clean water exits from the top. Manufactured from durable, UV-stabilized polypropylene, this pre-filter resists corrosion and weathering. It requires no power, no filter media, and minimal maintenance, making it an economical and reliable solution for agricultural water treatment. | PP Hydro CyclonePP Hydro Cyclone (or PP Hydrocyclone) is a robust sand separation device manufactured from high-quality polypropylene, designed to remove sand and heavy suspended solids from irrigation water using centrifugal force. The PP Hydro Cyclone features a hydrodynamically optimized internal geometry that creates maximum centrifugal action, effectively separating particles as fine as 50 microns. The PP construction offers outstanding resistance to corrosion, chemicals, and UV radiation, ensuring long-lasting performance. This filter requires no consumable filter media and operates solely on water pressure, making it highly cost-effective. Available in 2", 2.5", and 3" sizes with various connection options, the PP Hydro Cyclone is ideal for agricultural irrigation, water treatment, and aquaculture applications. | Cyclone Sand FilterA Cyclone Sand Filter is a high-efficiency solid-liquid separation device that uses centrifugal force to remove sand and other dense particles from water. The water enters the cyclone chamber tangentially, creating a spiraling vortex that accelerates heavier particles toward the outer wall and downward to the collection cone. The cleaned water exits through the top outlet. This cyclone sand filter is manufactured from durable polypropylene, offering excellent corrosion resistance and UV stability. It operates without any moving parts, filter media, or external power, resulting in minimal maintenance requirements and low operating costs. Ideal for agricultural irrigation systems, well water treatment, and industrial applications where sand removal is critical for protecting downstream equipment. |
A PP Hydro Cyclone (or hydrocyclone filter) is an advanced sand separation device made from high-grade polypropylene. It uses centrifugal force to efficiently remove sand, grit, and heavy suspended solids from irrigation water.
It operates purely on water pressure without any moving parts or electricity. Water enters the unit tangentially, creating a high-speed vortex (centrifugal action). Heavy suspended particles are driven outward against the cyclone walls, spiral downward into a collection chamber, while clean water exits from the top center outlet.
It is designed to effectively separate fine sand and suspended solid particles as small as 50 microns, depending on the specific flow rate and inlet pressure.
The body is constructed from premium-grade Polypropylene (PP), offering exceptional durability and robustness for demanding agricultural environments.
PP construction provides outstanding resistance to:
Corrosion from water and fertilizers
Chemicals commonly used in fertigation and water treatment
UV radiation for prolonged exposure to sunlight
No. The PP Hydro Cyclone requires no consumable filter media, screens, or replacement cartridges, making it virtually maintenance-free and highly cost-effective over its lifespan.
It is available in standard inlet/outlet sizes including 2", 2.5", and 3", with various connection options to fit existing piping networks.
Agricultural irrigation systems (drip, sprinkler, and micro-irrigation)
Water treatment plants (as a primary pre-filtration stage)
Aquaculture systems requiring sediment-free water
By removing abrasive sand and heavy solids upfront, it prevents premature wear, clogging, and damage to downstream valves, drip emitters, sprinklers, and secondary screen/disc filters.
No. It operates entirely hydraulically using water pressure from your pump or water source.
It features a hydrodynamically optimized internal geometry specifically engineered to maximize centrifugal action and maintain optimal hydraulic efficiency with minimal pressure drop.
Accumulated sediment collected in the bottom collection chamber can be easily purged periodically by opening a manual or automated flush valve attached to the sediment drain port.
Yes. Because it is manufactured from chemical-resistant polypropylene, it is fully compatible with water containing dissolved fertilizers and agricultural chemicals.
When operated within its recommended flow range, the pressure drop is kept minimal, typically ranging between 0.2 to 0.5 bar, ensuring your irrigation system's overall hydraulic performance remains high.
Yes. The polypropylene material is treated with UV stabilizers, making it durable and weather-resistant for outdoor agricultural installations without needing a protective shed.
It is best used as a primary pre-filter to remove heavy sand and inorganic solids. For optimal protection, follow it with a secondary screen or disc filter to catch any remaining fine organic matter.
It typically offers versatile connection options such as BSP/NPT threaded or flanged connections for easy integration into PVC or HDPE mainline pipes.
Flow capacity varies depending on the model size (2" to 3"):
2" models: Ideal for moderate flow rates.
2.5" and 3" models: Suited for higher commercial and agricultural discharge volumes. (Consult specific product datasheets for exact flow ranges in $\text{m}^3\text{/h}$ or LPM).
While screen filters trap particles on a mesh (which can blind or clog quickly with heavy sand), a hydrocyclone uses centrifugal force to continuously throw heavy particles out of the main water stream without blinding.
Maintenance is minimal. It mainly involves checking the sediment collection chamber regularly and flushing out accumulated sand, especially during peak irrigation seasons or when utilizing sandy borewell water sources.
No. Thanks to its lightweight polypropylene construction, it is significantly lighter than traditional cast iron or heavy steel hydrocyclones, making transportation and installation much easier.
Hydrocyclones are primarily designed for inorganic solids (sand, grit, silt). Organic impurities like algae have a specific gravity close to water and are better handled by disc filters, media filters, or screen filters.
It is ideal for pressurized water sources containing high levels of sand and suspended grit, such as borewells, open wells, and canal water intakes.
